The RAS-5000 is a streaming integrated amplifier by Rotel that delivers 140 watts x 2 channels into 8 ohms and 220 watts x 2 channels into 4 ohms. It was released in November 2023. It is a 2-channel design using a Class A/B output stage. A minimum impedance of 4 ohms makes it compatible with a wide range of loudspeakers. It has a built-in DAC (ESS), so you can play digital sources directly with no separate DAC unit needed. The Rotel RAS-5000 has an MSRP of $2,999.
Rotel RAS-5000 Amplifier Internal View
There are 10 Rotel amplifiers in our database. Below you can see the main specs of these amps.
Rotel Integrated Amplifier Series
Performance Specs
One of the most important factors when deciding on an integrated amplifier is its power ratings and compatibility with your speaker's impedance requirements. The Rotel RAS-5000 is rated at 140 watts RMS into 8-ohms. Rotel provides this wattage at a THD (Total Harmonic Distortion) of 0.03% which is an important indicator of distortion at the given values (lower THD is better).
Here are the main highlights of its performance specs:
- 140 watts into 8-ohms (20 Hz-20 kHz) at 0.03%
- 220 watts into 4-ohms
- 4-ohms Min Impedance (allows compatibility with a wide range of loudspeakers)
- 103dB Signal to Noise Ratio
How loud will 140 watts actually play in your room? →
Wiring more than one pair of speakers to it? Check the load first →
Which speakers suit the Rotel RAS-5000?
140 W into 8 ohms, 220 W into 4, rated down to 4 ohms.
We rank every passive speaker we cover against it on power, impedance safety and current
delivery.
Need more power?
Rotel RAS-5000 is rated at 140 watts into 8 ohms, which puts it in our 121 to 180 watts band. The next band up is Over 180 watts, which is worth about 2.3dB more output. That is a real difference in headroom on peaks, and a modest one in how loud the system plays - power and loudness are not the same thing.
Before buying watts, check what your speakers actually need: the amp and speaker matcher works it out from their sensitivity, impedance and your room. Plenty of systems are better served by the 91 to 120 watts band and better speakers.
When pairing the Rotel RAS-5000 with a passive Bookshelf (Stand mount) or Passive Floor Standing (Tower) speaker, you have to check if their Max Power Range is below the max wattage of the amp for the given impedance levels.
Operating your amp outside of this max range may damage the speakers.
What size of room is the Rotel RAS-5000 Amplifier good for?
An essential deciding factor is the size of the room in which you intend to employ the Rotel RAS-5000 amplifier. Here, taking into account its maximum power parameters, we analyzed its applicability to various size environments:
| Listening Environment |
Suitability |
| Near-field | Are you nuts? |
| Small Room | Bad |
| Mid-size Room | Poor |
| Large Room | Good |
| Very Large Room | Good |
Inputs and Outputs
Besides the performance specs of the Rotel RAS-5000, the next important feature set that you have to evaluate is the input and output selections that it offers.
Rotel RAS-5000 has total of 1 Analog inputs .
Rotel RAS-5000 Back View (Click the image for the larger version)
Inputs
- Total Number of Analog Inputs: 1
- 1 Optical Digital Input
- USB Input:
- USB Type-A port for audio playback via flash drive
- USB Type-B input for connecting a computer
- HDMI Input (eARC)
Outputs
- Speaker Outputs
- Stereo RCA, Sub Preamp Outputs
- 3.5mm Headphone Output
- Subwoofer Output (1)
Bluetooth Connectivity
Rotel RAS-5000 features built-in Bluetooth for wireless music streaming from your Bluetooth-enabled devices such as Apple iPod/iPhone/iPad, Android smartphone/tablet, Windows PC, Mac computers/laptops.
Among the amps in the same price range, these are the 5 amps that have Bluetooth Connectivity:
Rotel RAS-5000 supports the following Bluetooth Codecs when used with supported devices:
Phono Input
Rotel RAS-5000 doesn't have a phono input so in order to play your vinyl albums, Rotel RAS-5000 has to be paired with a Phono Preamp that is MM (Moving Magnet) or/and MC (Moving COil) depending on your cartridge type.
Subwoofer Output
Rotel RAS-5000 has a dedicated subwoofer output which can be used to connect it directly to a powered subwoofer via an LFE(Low Frequency Effects) cable.
Check our
Powered Subwoofers page to find a subwoofer that will work with Rotel RAS-5000 amp and your speakers.
DAC and Digital Music
The Rotel RAS-5000's built-in DAC allows the connection of digital sources directly, eliminating the need for an external DAC. The DAC chip that is used in the RAS-5000 is the
ESS, and supports resolutions up to
32-bit, 384KHZ.
Rotel RAS-5000 Pros and Cons
Drawn from the published figures on this page, not from listening.
- ✓140 watts per channel into 8 ohms, 220 into 4.
- ✓Signal-to-noise ratio of 103dB, so the amplifier itself should be inaudible between tracks.
- ✓Built-in DAC handling 32-bit / 384 and MQA, so a TV, computer or streamer can connect digitally with nothing in between.
- ✓Digital inputs cover 1 optical and USB.
- ✓Streams over the network without a separate streamer: AirPlay 2, Chromecast built-in and Roon.
- ✓Bluetooth (aptX HD,AAC,SBC) for playing straight from a phone.
- ✓Pre-outs (Stereo RCA, Sub) leave room to add a power amplifier or an active subwoofer later.
- ✓Headphone output (3.5mm).
- ✓5-year parts warranty, longer than most of the market.
- ✓Detachable mains lead (IEC 3-prong).
- ✗Only 1 analogue input, so a second source means unplugging the first.
Rotel RAS-5000 External Dimensions and Weight
Rotel RAS-5000 has external dimensions of (H x W x D) 5-5/8inch x 17-1/16inch x 17-9/16inch (143.0mm x 434.0mm x 447.0mm ). The unit weighs
15.73 kg (34.6 lbs).
Base Surface Area
Base surface area of an integrated amplifier may become an important decision factor when the space in your room or desk is limited.
The base area of the Rotel RAS-5000 is approximately 1940.0cm2 / 300.7inch2.
- Width: 434.0mm (17-1/16")
- Height: 143.0mm (5-5/8")
- Depth: 447.0mm (17-9/16")
- Weight: 15.73 kg (34.6 lbs)
- Base Surface Area: ~1940.0cm2 / 300.7inch2
- Volume: ~27.7 liter / 7.3 gallon
Rotel RAS-5000 - Top View
Rotel RAS-5000 screen
Available colors
Rotel RAS-5000 is available in Black and Silver color options.
What's in the Box of Rotel RAS-5000?
Here are the items that are included inside the box of RAS-5000:
- Stereo integrated amplifier
- 58-inch AC power cord
- Remote control
- CR2035 3V battery (pre-installed)
- 2 Wifi antennas
- 1 Bluetooth antenna
- 5-feet USB-B to USB-A cable
- 57-inch Ethernet cable
- USB Audio Driver thumbdrive
- Quick Installation Guide
- Important Safety Instructions
- Addendum For Roon Ready
- Spotify Connect Instructions
Official Product Page
Official manufacturer's product page for the Rotel RAS-5000 Integrated Amplifier can be found below:
Official Product Page for Rotel RAS-5000
Warranty
5 Years of parts warranty and 5 Years of labor warranty is generally provided for the Rotel RAS-5000 by the manufacturer.
Rotel RAS-5000 Lifestyle
| General |
| Brand |
Rotel |
| Full Model Name |
Rotel RAS-5000 |
| Release Date |
November 2023 |
| Amplifier Type |
Integrated Amplifier |
| Number of Channels |
2 |
| Amp Class |
Class A/B |
| Amplifier Technology |
Solid State |
| Performance |
| Watts RMS per Channel into 8-ohms |
140 watts |
| Watts RMS per Channel into 6-ohms |
N/A |
| Watts RMS per Channel into 4-ohms |
220 watts |
| Frequency Bandwidth |
20 Hz-20 kHz |
| THD |
0.03% |
| Minimum Impedance |
4 |
| Signal to Noise Ratio |
103 dB |
| Digital Music |
| Built-in DAC |
Yes |
| DAC Specs |
ESS |
| Bluetooth |
Yes |
| WiFi |
802.11ac |
| Ecosystem |
| Apple AirPlay |
Yes |
| Apple AirPlay2 |
Yes |
| DTS Play-Fi |
No |
| Chromecast built-in |
Yes |
| Roon |
Ready |
| HEOS |
No |
| BluOS |
No |
| CONNECTIONS |
| Total Analog Inputs |
1 |
| Phono Input |
No |
| Optical Digital Inputs |
1 |
| Coaxial Digital Inputs |
No |
| USB Input |
Yes |
| USB Type |
USB Type-A port for audio playback via flash drive, USB Type-B input for connecting a computer |
| Preamp Outputs |
Stereo RCA, Sub |
| Pre-out / Main-in Loop |
No |
| Headphone Output |
3.5mm |
| Subwoofer Output |
Yes |
| Removable Power Cord |
IEC 3-prong |
| PHYSICAL SPECS |
| Height |
143.0mm (5-5/8") |
| Width |
434.0mm (17-1/16") |
| Depth |
447.0mm (17-9/16") |
| Weight |
15.73 kg (34.6 lbs) |
| Available Colors |
Black,Silver |
| OTHER |
| Screen |
Front Panel Color LCD |
| Parts Warranty |
5 Years |
| Labor Warranty |
5 Years |
