PB 5000 R Evolution is a Ported type Powered Subwoofer by SVS with a frequency range of 13-180 Hz. It was released in 2025. It features 1 x 15" Woofer, and powered by a 2000 watts amplifier.
PB 5000 R Evolution is a member of SVS's PB series of Powered subwoofers. PB stands for "Ported Box" and represents the ported subwoofers of SVS which are generally larger compared to its sealed subwoofers, and produce greater dynamic output and play lower. Below you can see the main specs of these subwoofers as well as review and comparison links.
See all 8 SVS PB models compared »
Frequency Response
Where should the crossover go? → · What will your room do to this bass? →
SVS PB 5000 R Evolution has a Frequency response range of 13-180 Hz. Thanks to its 1 x 15-inch driver and 2000 watts RMS (5000 watts MAX) amplifier, at 13Hz the PB 5000 R Evolution can generate bass levels that is even below 20Hz which is considered to be the bottom limit of Full Range sound (20Hz -20kHz) that human can hear.
Here we have a comparison of how PB 5000 R Evolution's Low and High frequency values compare with the average, max and min Low and High frequency values in its class.
Low Frequency
Powered Subwoofers
High Frequency
Subwoofer Speakers
Among all subwoofers in our database with a max MSRP price of 3000$, these are the 5 Powered Subwoofer models that can reach deeper bass levels than the SVS PB 5000 R Evolution's 13Hz:
Inputs and Outputs
SVS PB 5000 R Evolution External Dimensions and Weight
SVS PB 5000 R Evolution has external dimensions of (Height x Width x Depth) (595.3 x 520.7 x 730.3mm ).
Base Surface Area
Base surface area of a loudspeaker may become a determining factor when the space in your room or desk is limited.
The base area of SVS PB 5000 R Evolution is approximately 3802.7cm2 / 589.4inch2.
Find speakers that fit your shelf or alcove →
WeightThe SVS PB 5000 R Evolution weighs 69.81kg / 153.6lbs. Weight of a subwoofer is an important factor when you need to move and reposition the unit often to find the optimal positioning, also known as 'Subwoofer Crawling'. Here is a comparison of how PB 5000 R Evolution's weight compares with the average, max and min weights in its class.
Weight
All Subwoofer Speakers
Weight
Subwoofer Speakers under $3000
Recommended Accessories
Here is a list of accessories that we think you may need for the SVS PB 5000 R Evolution.
Warranty
5 Years of parts warranty and 5 Years of labor warranty is generally provided by the manufacturer.
| General |
| Brand | SVS |
| Full Model Name | SVS PB 5000 R Evolution |
| Type | Powered Subwoofer |
| Release Date | 2025 |
| Frequency Response | 13-180 Hz |
| Enclosure Type | Ported |
Amplifier & Driver |
| Power (Peak) | 5000 watts |
| Woofer | 15-inch |
| Controls & Connections |
Physical |
| Dimensions (HxWxD) | 23-7/16" x 20-1/2" x 28-3/4" (595.3 x 520.7 x 730.3mm) |
| Weight | 69.81 kg (153.9 lbs) |
| Parts Warranty | 5 Years |
| Labor Warranty | 5 Years |
