Klipsch Heritage Klipschorn AK7 is a 3-way Passive Acoustic Suspension Floor-standing speaker by Klipsch. It features a 1" Tractrix horn Tweeter, 1 x 3" Midrange and 1 x 15" fiber-composite with a trihedral exponential folded horn Woofer. The speaker has a frequency range of 34-19k Hz and a sensitivity of 103 dB. Klipsch Klipschorn AK7 has an MSRP of 17998$ per pair.
Klipsch replaced the older AK6 with this model. Follow the link to read our detailed comparison of these models:
Compare Klipsch Klipschorn AK7 vs Klipsch Klipschorn AK6
Klipsch Klipschorn AK7 Lifestyle
Klipsch's Heritage Series of Loudspeakers
AK7 is a member of Klipsch's Heritage series of Passive speakers. Below you can see the main specs of these speakers.
Klipsch Heritage Series Speakers
Klipsch Heritage Series Speakers
**This post contains affiliate links, and I will be compensated if you make a purchase after clicking through my links. As an Amazon Associate I earn from qualifying purchases.
Frequency Response of the Klipsch Klipschorn AK7 Speaker
Klipsch Klipschorn AK7 has a Frequency response range of 34-19k Hz at ±-4.0dB and Power Range of up to 100 watts. With a minimum frequency of 34 Hz, AK7 delivers deep bass that will likely satisfy most listeners, especially those who enjoy music. However, movie enthusiasts and music fans who prefer a full range of sound may still benefit from adding a subwoofer.
Visit our Powered Subwoofers section to find out more about the available subwoofer options.
Here we have a comparison of how AK7's Low and High frequency values compare with the average, max and min Low and High frequency values in its class.
Low Frequency
Floor-standing Speakers
High Frequency
Floor-standing Speakers
Among the speakers in our database with a max MSRP price of 20000$ (Pair), these are the 5 Passive Floor-standing speakers that have the deeper bass levels than the Klipsch Klipschorn AK7's 34Hz:
Crossover frequency of the Klipsch Klipschorn AK7?
AK7 is a 3-way speaker and its crossover frequency between the woofer and the midrange set to 380Hz and the Crossover frequency between the midrange and the tweeter is set to 2900Hz.
Impedance and Sensitivity
Klipsch Klipschorn AK7's nominal impedance level is
8 ohms but can go down to as low as
4 ohms, and has a sensitivity of
103 dB.
Sensitivity
Floor-standing Speakers
8 Ohms is pretty much the standard nominal impedance amongst stereo speakers and amplifiers so Klipsch Heritage Klipschorn AK7 is not considered a difficult to drive speaker from nominal Impedance perspective.
Sensitivity
103dB of the Klipsch Heritage Klipschorn AK7 is considered a high sensitivity compared to average stereo speaker which makes AK7 an easy to drive from Sensitivity perspective. If you are planning to power your speaker with a Tube amp which are generally very low power, the Klipsch Klipschorn AK7 will be a good choice.
Minimum Impedance of the Klipsch Klipschorn AK7
Even though the nominal impedance of the AK7 is 8 ohms, the minimum impedance level of this speaker according to Klipsch is 4 ohms Klipsch Heritage Klipschorn AK7 so while choosing an amplifier, you should ideally check if the unit you are considering can provide this impedance level.
Check the amplifiers that are in a similar price range to the Klipsch Klipschorn AK7:
Input Type
AK7 has Binding post type connectors and lets bi-amping/bi-wiring. Bi-wiring can enhance the overall transparency of your loudspeakers by using separate speaker wires for the low and high-frequency drivers from a single amplifier. Bi-amping, on the other hand, involves using separate amplifiers for the high and low-frequency drivers, potentially resulting in a greater dynamic range and reduced distortion.
Klipsch Klipschorn AK7 Back View
Klipsch Klipschorn AK7 External Dimensions and Weight
Klipsch Klipschorn AK7 has external dimensions of (Height x Width x Depth) 53 x 31-1/4 x 28-1/4inch (1347.0 x 794.0 x 718.0mm ).
Base Surface Area
Base surface area of a loudspeaker may become a determining factor when the space in your room or desk is limited.
The base area of Klipsch Klipschorn AK7 is approximately 5700.9cm2 / 883.6inch2.
To get a better perspective on the real life size of Klipsch Klipschorn AK7, let's compare it with a standard size Compact Disc which has a diameter of 4.7inch (120mm).
Klipsch Klipschorn AK7 Speaker Size Compared to a Compact Disc
Here we place the Klipsch Klipschorn AK7 virtually next to a standard width amplifier and turntable on a media center to get a better idea about the size.
Klipsch Klipschorn AK7 Floor-standing Speaker next to a Media Stand
WeightThe Klipsch Klipschorn AK7 weighs 118.00kg / 259.6lbs per piece. Here is a comparison of how AK7's weight compares with the average, max and min weights in its class.
Weight
All Floor-standing Speakers
Weight
Floor-standing Speakers under $20000
Cabinet type and Materials
Klipsch Klipschorn AK7 has a
Acoustic Suspension type cabinet and a MDF/Wood veneer finish. Acoustic Suspension loudspeakers aka Sealed speakers have no openings such as ports or slots.. They can be designed smaller, the bass is more accurate and tighter compared to ported designs but doesn't go as low on the lower end in general.
Available colors
Klipsch Klipschorn AK7 is available in American Auburn, Black Ash and American Walnut.
Klipsch Klipschorn AK7 Colors
Does the Klipsch Klipschorn AK7 come with a Grille?
AK7 comes with cloth grilles in Silver Metallic color choices. The purpose of the grille is to protect the delicate driver elements from external impacts while still allowing the sound to pass as clearly as possible.
Klipsch Klipschorn AK7 with Grille
What's in the Box of Klipsch Klipschorn AK7?
Here are the items that are included inside the box of AK7:
2 Loudspeaker cabinets2 Subwoofer cabinets2 GrillesOwners ManualCongratulations letterKlipsch brochure
Recommended Accessories
Here is a list of accessories that we think you may need for the Klipsch Heritage Klipschorn AK7.
Official Product Page
Official manufacturer's product page for the Klipsch Heritage Klipschorn AK7 speaker can be found below:
Official Product Page for Klipsch Klipschorn AK7
Warranty
10 Years of parts warranty and 10 Years of labor warranty is generally provided by the manufacturer.
Klipsch Klipschorn AK7 Lifestyle
