The Magni Unity is a headphone amplifier by Schiit Audio. It was released in 2024. The Magni Unity has an MSRP of $119.
Performance Specs
The Magni Unity drives headphones rather than loudspeakers, so its power is quoted into headphone impedances instead of into 8 ohms: 3.0 W @ 16 ohms, 2.5 W @ 32, 1.5 W @ 50, 415 mW @ 300, 220 mW @ 600. Its output impedance is 0.1 ohms - a low figure keeps the frequency response of a low-impedance headphone from being altered by the amplifier. Schiit Audio quotes a THD (Total Harmonic Distortion) of Less than 0.0001% (-116 dB) at 2 V RMS into 300 ohms, low gain (lower is better).
Here are the main highlights of its performance specs:
- 122dB Signal to Noise Ratio
Inputs and Outputs
Besides the performance specs of the Magni Unity, the next important feature set that you have to evaluate is the input and output selections that it offers.
Magni Unity has total of 1 Analog inputs .
Inputs
- Total Number of Analog Inputs: 1
Outputs
- Preamp Outputs
- 1/4 Headphone Output
DAC and Digital Music
The Magni Unity can take an optional DAC module, which lets you feed it a digital source directly instead of adding a separate converter.
Magni Unity Pros and Cons
Drawn from the published figures on this page, not from listening.
- ✓Output impedance of 0.1 ohms is low enough that it will not alter the frequency response of low-impedance headphones.
- ✓Delivers 2,500 mW into 32 ohms, comfortably more than most headphones need.
- ✓A preamp output means it can also feed active speakers or a power amplifier, so it is not limited to headphone listening.
- ✗The DAC is an optional module rather than fitted as standard, so a digital source costs extra.
- ✗It has no speaker terminals - this drives headphones, not loudspeakers.
Magni Unity External Dimensions and Weight
Magni Unity has external dimensions of (H x W x D) 1-1/4 x 5 x 3-1/2 inch (31.8 x 127 x 88.9 mm ). The unit weighs
0.91 kg (2 lbs).
Base Surface Area
Base surface area of an integrated amplifier may become an important decision factor when the space in your room or desk is limited.
The base area of the Magni Unity is approximately 112.9cm2 / 17.5inch2.
- Width: 127.0mm (5")
- Height: 31.8mm (1-1/4")
- Depth: 88.9mm (3-1/2")
- Weight: 0.91 kg (2 lbs)
- Base Surface Area: ~112.9cm2 / 17.5inch2
- Volume: ~0.4 liter / 0.1 gallon
| General |
| Brand |
Schiit Audio |
| Full Model Name |
Schiit Magni Unity |
| Release Date |
2024 |
| Amplifier Type |
Headphone Amplifier |
| Amplifier Technology |
Solid State |
| Performance |
| Headphone Output Power |
3.0 W @ 16 ohms, 2.5 W @ 32, 1.5 W @ 50, 415 mW @ 300, 220 mW @ 600 |
| Output Impedance |
0.1 ohms |
| Frequency Bandwidth |
20 Hz-20 kHz |
| THD |
Less than 0.0001% (-116 dB) at 2 V RMS into 300 ohms, low gain |
| Signal to Noise Ratio |
122 dB |
| Digital Music |
| Built-in DAC |
Optional |
| Bluetooth |
|
| WiFi |
|
| CONNECTIONS |
| Total Analog Inputs |
1 |
| Preamp Outputs |
Yes |
| Headphone Output |
1/4 |
| Removable Power Cord |
|
| PHYSICAL SPECS |
| Height |
31.8mm (1-1/4") |
| Width |
127.0mm (5") |
| Depth |
88.9mm (3-1/2") |
| Weight |
0.91 kg (2 lbs) |
| OTHER |
| Parts Warranty |
|
| Labor Warranty |
|
|
Model |
Watts (8Ω) |
Min. Impedance |
DAC |
Phono |
 |
Compare |
— | — | — | — |
Does the Magni Unity use vacuum tubes?
No. The Magni Unity is a solid-state amplifier - there are no vacuum tubes in it.
Does the Magni Unity have a built-in DAC?
It can. The Magni Unity takes an optional DAC module, so you can have digital inputs built in, but it is not fitted as standard.
Does the Magni Unity have a headphone output?
Yes. The Magni Unity has a 1/4-inch headphone output on the front panel for private listening.
How much does the Magni Unity cost?
The Magni Unity has a manufacturer's list price (MSRP) of $119.
