Revel W553L vs Revel W263 Speaker Comparison

In this review, we will be comparing two different types of speakers by Revel. Revel W553L is a Center Channel speaker whereas the W263 is a In-wall speaker.

Let's have a brief look at the main features of Revel W553L and Revel W263 first before getting into our more detailed comparison.

Key Specs	Revel W553L	Revel W263
Brand	Revel United States · founded 1996	Revel United States · founded 1996
Design	2-way	2-way
Tweeter	1"	1"
Woofer	2 x 5.25"	6.5"
Sensitivity	90.5 dB	88 dB
Impedance	8 ohms	8 ohms
Power range	10 - 150 W watts	10 - 100 W watts
Weight	2.99kg / 6.6lbs	1.54kg / 3.4lbs
Dimensions (H x W x D)	15-1/8" x 7-7/16" x 2-15/16" 384.2 x 188.9 x 74.0mm	10.75" x 8.31" x 3.46" 273 x 211 x 88 mm

W553L and W263 are members of Revel's Architectural series of speakers. Below you can find the loudspeakers from this series.

Revel Architectural Series History

Model	Body	Frequency	Sensitivity	Impedance	Woofer
Revel W253L	In-wall	55-18kHz	91 dB	8Ω	2 x 5.25"
Revel W553L	Center Channel		90.5 dB	8Ω	2 x 5.25"
Revel W383	In-wall		89 dB	8Ω	1 x 8"
Revel W763	In-wall		89 dB	8Ω	1 x 6.5"
Revel W783	In-wall		89 dB	8Ω	1 x 8"
Revel W990	In-wall		89 dB	8Ω	1 x 9"
Revel W228Be	In-wall	35-40k Hz	90 dB	6Ω	2 x 8"
Revel W126Be	In-wall	55-40k Hz	89 dB	6Ω	1 x 6.5"
Revel W226Be	In-wall	45-40k Hz	90 dB	6Ω	2 x 6.5"
Revel W263	In-wall		88 dB	8Ω	1 x 6.5"

The sections below take each area in turn: drivers, frequency response, physical size and what you get in the box.

Drivers

Both W553L and W263 are 2-way speakers.

Revel W553L

Revel W263

TweeterWoofer

Front view, drawn to scale - cabinets and drivers share one scale, so sizes are directly comparable. Hover a driver for its size.

Driver	Revel W553L	Revel W263
Driver Setup	2-way	2-way
Tweeter	1-inch	1-inch
Midrange	-	-
Woofer	2 x 5.25-inch	1 x 6.5-inch

W553L features a 1" Tweeter and 2 x 5.25" Woofer. On the other hand, the W263 features a 1" Tweeter and 1 x 6.5" Woofer.

Frequency Response

W553L and W263 has exactly the same frequency range of .

The graph below depicts how these two speakers compare with the max, min and average Low Frequency values of other speakers in the Center Channel class in our database.

Low Frequency

Center Channel Speakers

W553L

W263

Min

Average

Median

Impedance and Sensitivity

W553L and W263 have the same Impedance of 8 ohms but where they differ is the sensitivity levels. W553L sensitivity is rated at 90.5 dB and the W263's is at 88 dB. This 2 dB difference makes the Revel W553L a more sensitive speaker compared to Revel W263, hence will play louder with the same amount of watts.

Sensitivity

Center Channel Speakers

W553L

W263

Min

Average

Median

Power Range

Power range is the range of input power in watts RMS that a loudspeaker is designed to handle. Staying within that range gives nominal performance; driving the speaker beyond its maximum wattage can damage it.

W553L can handle a max power of 150 watts RMS, whereas W263 has a max power handling value of 100 watts RMS, 50 watts less than the W553L.

Note that higher power handling does not make a speaker louder: that depends mainly on sensitivity and impedance. The calculator below shows how loud each of these actually plays on a real amplifier.

Which plays louder on your amplifier?

Starting with a popular amplifier - change it to the one you own, or any you are considering, and watch both numbers move.

Amplifier - change this

Distance

Playing as

Revel W553L

Revel W263

Input Type and Bi-Amping / Bi-Wiring

W553L features Spring clip type posts and W263 has a Spring clip type posts. None of these speakers feature bi-amping/bi-wiring.

Physical Specs

The size of a speaker can sometimes be an important decision factor due to space constraints or in some cases purely for esthetic reasons. In this section, we are going to compare Revel W553L's and Revel W263's external dimensions. Revel W553L has external dimensions of 384.2 x 188.9 x 74.0mm () whereas Revel W263 has external dimensions of 273 x 211 x 88 mm ().

Revel W553L is 22.1mm narrower and 14mm less deeper than Revel W263 but it is also 111.2mm taller.

Size, drawn to scale

Both speakers and both views share one scale, so everything here is directly comparable. Hover a box for its dimensions.

One scale for both, standing on the same surface and pushed back to the same wall, so the deeper one visibly sticks out further.

Revel W263 needs about 33% more floor or shelf area. Revel W553L is 111mm taller.

Reasons to choose Revel W553L over Revel W263

Max Input Power	150 watts vs 100 watts	Handle more power from your amplifier
Sensitivity	90 dB vs 88 dB	Play louder with same amount of amplification power
Number of Woofers	2 vs 1	More woofers
Base Surface Area	139cm² vs 185cm²	Takes less floor space

Reasons to choose Revel W263 over Revel W553L

Woofer Size	6.5 inches vs 5.25 inches	Larger woofer
Height	273mm vs 384mm	Easier to fit in smaller spaces
Price per pair*	420USD vs 545USD	costs less (*prices may change depending on the seller, location and time)

Revel W553L vs Revel W263 Specs Table

Detailed comparison of specifications

General	Revel W553L	Revel W263
Brand	Revel	Revel
Speaker Type	Center channel speaker	Passive In-wall Speaker
Power Range	10 - 150 W watts	10 - 100 W watts
Sensitivity	90.5 dB	88 dB
Impedance	8 ohms	8 ohms
Frequency Response
Drivers
Woofer Quantity	2	1
Woofer Size	5.25"	6.5"
Woofer Composition
Tweeter Size	1"	1"
Aimable Tweeter	No	No
Midrange Driver	No	No
Physical Specs
Height	384.2mm (15.1")	273.0mm (10.7")
Width	188.9mm (7.4")	211.0mm (8.3")
Depth	74.0mm (2.9")	88.0mm (3.5")
Weight	2.99kg (6.6lbs)	1.54kg (3.4lbs)
Enclosure
Moisture Resistancy	No	No
Connections
Other
Parts Warranty	Lifetime	Lifetime
Labor Warranty	Lifetime	Lifetime

Verdict

Siblings in Revel's Architectural series, so they share a family sound. It comes down to size, output and price.

Area	Better	Why
Amplifier needs	A	Revel W553L is more sensitive (90dB vs 88dB), so it goes louder on the same amplifier.
Headroom	A	Revel W553L takes more power (150W vs 100W) - more in hand in a big room.
Size	depends	Similar cabinet size - neither is easier to fit.
Type	depends	A Passive Center Channel against a Passive In-wall - a different job rather than a better one.
Price	B	Revel W263 is cheaper - $420 against $545, about 23% less.

A Revel W553L B Revel W263
depends neither is better in the abstract - it turns on your room, your system or how you will use them. Only specs published for both speakers are judged; anything missing on either side is left out rather than guessed.

Which should you choose?

The usual trade-off: Revel W553L measures better, Revel W263 costs about about 30% more% less. Whether that gap is worth the money is the call only you can make - and in a normal room it is often smaller than the numbers suggest. If your amplifier is modest, vintage or valve-based, Revel W553L is the safer partner - the other will want more current or more watts to sound its best.

And remember what a spec sheet cannot show: how each looks in your room and whether the finish suits it, what dealer support and warranty are like where you live, and how they actually sound to you. If you can hear them first - ideally with your own music - that will tell you more than any number above.
