In this review, we will be comparing Performa4 B140 and R-101SW, two Powered Subwoofer speakers from Revel and Klipsch. Being Powered subwoofers, they both have built-in amplifiers so you don't need an external power amp or an integrated amp to power them. Let's have a brief look at the main features of Revel Performa4 B140 and Klipsch R-101SW first before getting into our more detailed comparison.
The sections below take each area in turn: driver and amplifier, frequency response, physical size and connectivity.
Drivers
The efficiency of a subwoofer is directly proportional to the total radiating are squared hence the woofer quantity and diameter.Revel Performa4 B140and Klipsch R-101SW have the same driver set up: Both subwoofers have 1 x 10" drivers.
Frequency Response
Performa4 B140 has a frequency range of 26-150 Hz whereas R-101SW has a frequency range of 29.5-160 Hz. With a minimum frequency of 26Hz, the Performa4 B140 can go slightly deeper then the R-101SW's min frequency of 30Hz.
Below graphs depict how these two speakers compare with the max, min and average values of the Min and Max Frequencies of other speakers in the Subwoofer class in our database.
Low Frequency
Subwoofer Speakers
High Frequency
Subwoofer Speakers
Physical Specs
The size of a speaker can sometimes be an important decision factor due to space constraints or in some cases purely for esthetic reasons. In this section, we are going to compare Revel Performa4 B140's and Klipsch R-101SW's external dimensions. Revel Performa4 B140 has external dimensions of 376.2 x 430.2 x 438.2mm () whereas Klipsch R-101SW has external dimensions of 370.0 x 358.0 x 529.0mm (14-9/16inch x 14-1/16inch x 20-13/16inch).
Klipsch R-101SW is 72.2mm narrower and 6.2mm shorter than Revel Performa4 B140 but it is also 90.8mm deeper.
Size, drawn to scale
Both speakers and both views share one scale, so everything here is directly comparable. Hover a box for its dimensions.
One scale for both, standing on the same surface and pushed back to the same wall, so the deeper one visibly sticks out further.
Near-identical footprints. Klipsch R-101SW is 91mm deeper, so it stands that much further out from the wall.
Base Surface Area Comparison
Base surface area of a loudspeaker may become a determining factor when the space in your room or desk is limited.
The base surface area of the Revel Performa4 B140 is approximately 1885.1cm2 / 292.2inch2 and base area of the Klipsch R-101SW is approximately 1893.8cm2 / 293.5inch2. The Performa4 B140 requires 0% less surface area than the R-101SW which gives it a small advantage on placement in tight spaces.
Weight Comparison The weight of a subwoofer may become an important factor if you need to move and reposition the unit often to find the optimal positioning, also known as 'Subwoofer Crawling'. The Revel Performa4 B140 weighs 27.81kg / 61.2lbs and the Klipsch R-101SW weighs 13.91kg / 30.6lbs. This makes the Performa4 B140 100% heavier than the R-101SW.
Here is a comparison of how Performa4 B140 and R-101SW's weights compare with the average, max and min weights in Powered Subwoofer class.
Weight
All Subwoofer Speakers
 Low Frequency Response |
26 Hz
vs
30 Hz
|
Generates deeper bass |
 Base Surface Area |
1885cm2
vs
1893cm2
|
Takes less floor space |
 High Frequency Response |
160 Hz
vs
150 Hz
|
Generates higher frequency |
 Height |
370mm
vs
376mm
|
Easier to fit in smaller spaces |
 Price per pair* |
499USD
vs
3000USD
|
costs less (*prices may change depending on the seller, location and time) |
Size, drawn to scale
Both subwoofers and both views share one scale, so everything here is directly comparable. Hover a box for its dimensions.
One scale for both, standing on the same floor and pushed back to the same wall, so the bigger one visibly takes more of the room.
Near-identical footprints. Klipsch R-101SW stands 91mm further into the room.
| General |
Revel Performa4 B140 |
Klipsch Reference R-101SW |
| Brand |
Revel |
Klipsch |
| Speaker Type |
Powered Subwoofer |
Powered Subwoofer |
| Frequency Response |
26-150 Hz |
29.5-160 Hz |
Amplifier |
|
|
| Watts RMS (Continuous) |
750-watt RMS |
150-watt RMS |
| Watts Peak (Max) |
1500-watt RMS |
n/a |
Drivers |
|
|
| Woofer Quantity |
1 |
1 |
| Woofer Size |
10" |
10" |
| Woofer Composition |
|
Spun-Copper TCP |
| Tweeter Size |
- |
- |
| Aimable Tweeter |
No |
No |
| Midrange Driver |
No |
No |
| Firing Direction |
n/a |
front |
Physical Specs |
|
|
| Height |
376.2mm (14.8") |
370.0mm (14.6") |
| Width |
430.2mm (16.9") |
358.0mm (14.1") |
| Depth |
438.2mm (17.3") |
529.0mm (20.8") |
| Weight |
27.81kg (61.2lbs) |
13.91kg (30.6lbs) |
| Enclosure |
|
Bass Reflex |
| Grille |
n/a |
Yes |
| Moisture Resistancy |
No |
No |
Connections |
|
|
Other |
|
|
| Parts Warranty |
5 years |
2 Years |
| Labor Warranty |
5 years |
2 Years |
Different price classes - Revel Performa4 B140 costs roughly 6x what Klipsch R-101SW does. Before paying it, read the note below about two smaller subwoofers.
| Area | Better | Why |
|---|
| Bass depth | A | Revel Performa4 B140 goes deeper - 26Hz against 30Hz. A real difference, though most music has little content below 30Hz. |
| Amplifier power | A | Revel Performa4 B140 has the bigger amplifier - 750W against 150W RMS, about 7dB more on tap. In a large room that is headroom before the DSP starts limiting. |
| Driver area | evenly matched | Near-identical radiating area (10" against 10"). |
| Enclosure | evenly matched | Both are ported designs, so they roll off in much the same way. |
| Warranty | A | Revel Performa4 B140 carries 5 years on parts against 2 years. A subwoofer amplifier works harder than anything else in the system, so this is not a throwaway line. |
| Price | B | Klipsch R-101SW costs less - $499 against $3,000, about 83% less. |
A Revel Performa4 B140 B Klipsch R-101SW
depends neither is better in the abstract - it turns on your room, your system or how you will use them. Only specs published for both subwoofers are judged; anything missing on either side is left out rather than guessed.
Which should you choose?
The usual trade-off: Revel Performa4 B140 measures better, Klipsch R-101SW costs about 83% less. In a normal room, placement will make a bigger difference than the gap between these two. Two small subwoofers beat one big one in most rooms - a pair evens out the room modes in a way no single box can, whatever its specs. At $499 each, two Klipsch R-101SW cost about $998 against $3,000 for one of the other, which is worth a thought.
One thing outweighs everything above: where the subwoofer stands. Room modes can add or remove 10dB or more at a given seat, which is far larger than any difference on this page. Before spending more, try the sub in two or three positions - the crawl test, where you put it in the listening seat and crawl the room to find where the bass sounds best, costs nothing and usually beats an upgrade.
